THINKCAR ThinkTool Pad 10

Description

THINKCAR ThinkTool Pad 10

THINKTOOL PAD 10 Support 34+ Special Functions

1- Oil Resets
Reset  after the service, start a new cycle.

2.  DPF Regeneration

3. AFS(headlamp) Reset
The feature is used to initialise the adaptive headlamp system.
4. EGR Adaption
Reset EGR(Exhaust Gas Recirculation) valve post cleaning or replacement.

5. Brake-pad Reset

6. IMMO Service

7. Windows Calibration
This feature is designed to perform door window matching to recover ECU initial memory and recover the automatic UP and DOWN.

8. Coolant Bleeding

9. Steering Angle Reset

10. Injector Coding

11. Seat Calibration
Match seats with memory function when replaced and repaired.

12. Transport Mode
Reduce power consumption, limiting the vehicle speed, no wakeup doors network and disabling the remote control key.  transport mode needs to be deactivated to restore the vehicle to normal.

13.  Battery Matching

14. Airbag Reset

15. Tyre Reset

16.Cluster Reset
a) cluster reset, copy write or rewrite the value of km in the chip of cluster by using a car diagnostic computer and data cable to correct milage.
b) code new dash cluster

17. ABS Bleeding
Bleed the brake system to restore ABS .

18. Gear Learning

19. Language Change
This function is used to change the system language of the vehicle central control panel.

20. Adblue Reset
After the diesel exhaust treatment fluid (car urea) is replaced or filled up, urea reset operation is required.

21. Electronic  Throttle  Adaption
Elec. Throttle Adaption is to utilize the car decoder to initialize the throttle actuator so that the learningvalue of the ECU returns to the initial state.By doing these, the movement of the throttle (or idle motor)can be more accurately controlled, thus adjust the intake volume.

22. Suspension Matching
Adjust height of the body.  replacing the body height sensor in the air suspension system or control module or when the vehicle level is incorrect you need to perform this function to adjust the body height sensor for level calibration.

23. A/F Reset
This function is applied to set or learn Air/Fuel ratio parameters.

24. Nox Sensor Reset
Reset the catalytic converter learned value stored in the engine ECU.

25. TPMS Reset

26. A/T Learning
Code the gearbox self-learning improve gear shifting quality.

27. Sunroof Initialisation
This function can set the sunroof lock off,closed when it rains,sliding/tilting sunroof memory function,temperature threshold outside the car etc.

28. Stop/Start Reset

And much more……
